在使用治具清洗机清洗治具时，为防止治具变形或损坏，可从清洗前的准备、清洗过程中的参数控制以及清洗后的处理等多个环节采取相应措施，具体如下：

　　When using a fixture cleaning machine to clean fixtures, corresponding measures can be taken from multiple aspects such as preparation before cleaning, parameter control during the cleaning process, and post cleaning treatment to prevent fixture deformation or damage. The specific measures are as follows:

　　清洗前的准备

　　Preparation before cleaning

　　了解治具特性：在清洗前，需充分了解治具的材质、结构和耐受程度。不同材质如金属、塑料或复合材料，其耐温、耐压和耐化学腐蚀性不同，据此选择合适的清洗方式和参数。

　　Understand the characteristics of the fixture: Before cleaning, it is necessary to fully understand the material, structure, and tolerance of the fixture. Different materials such as metal, plastic, or composite materials have varying degrees of temperature resistance, pressure resistance, and chemical corrosion resistance. Based on this, choose the appropriate cleaning method and parameters.

　　检查治具状况：仔细检查治具是否有已有裂纹、损坏或松动部件，对于存在隐患的部位做好标记和记录。若有松动部件，需要进行紧固或拆卸，避免在清洗过程中因震动等原因导致损坏加剧。

　　Check the condition of the fixture: Carefully inspect the fixture for any cracks, damage, or loose parts, and mark and record any areas with potential hazards. If there are loose parts, they need to be tightened or disassembled to avoid further damage caused by vibration or other reasons during the cleaning process.

　　治具清洗机

　　Fixture cleaning machine

　　选择合适的清洗篮或夹具：根据治具的形状、尺寸和重量，挑选合适的清洗篮或夹具，确保治具在清洗机内能够被稳定固定，避免在清洗过程中发生碰撞或晃动。

　　Choose the appropriate cleaning basket or fixture: Based on the shape, size, and weight of the fixture, select the appropriate cleaning basket or fixture to ensure that the fixture can be stably fixed inside the cleaning machine, avoiding collisions or shaking during the cleaning process.

　　清洗过程中的参数控制

　　Parameter control during cleaning process

　　选择合适的清洗方式：根据治具的材质和污染程度，选择恰当的清洗方式。对于较脆弱的治具，避免使用高压喷淋等冲击力较强的方式，可采用超声波清洗，利用超声波的空化效应温和地去除污垢。

　　Choose the appropriate cleaning method: Select the appropriate cleaning method based on the material and degree of contamination of the fixture. For more fragile fixtures, avoid using high-pressure spraying or other strong impact methods. Ultrasonic cleaning can be used to gently remove dirt using the cavitation effect of ultrasonic waves.

　　控制清洗温度：清洗温度过高可能导致治具变形，尤其是对于塑料等材质的治具。应根据治具材质的耐受温度，合理设置清洗温度，一般不宜超过 60℃，防止因热应力导致治具变形。

　　Control cleaning temperature: Excessive cleaning temperature may cause fixture deformation, especially for fixtures made of plastic or other materials. The cleaning temperature should be set reasonably based on the tolerance temperature of the fixture material, generally not exceeding 60 ℃, to prevent deformation of the fixture due to thermal stress.

　　调整清洗时间：清洗时间过长可能会对治具造成不必要的损伤。需根据治具的污染程度和清洗机的性能，合理设定清洗时间，一般在 5-15 分钟之间，避免长时间清洗对治具造成过度腐蚀或磨损。

　　Adjust cleaning time: Excessive cleaning time may cause unnecessary damage to the fixture. The cleaning time should be reasonably set according to the pollution level of the fixture and the performance of the cleaning machine, generally between 5-15 minutes, to avoid excessive corrosion or wear of the fixture caused by long-term cleaning.

　　控制超声波功率：若采用超声波清洗，功率过高可能会产生过大的空化冲击力，对治具造成损坏。应根据治具的材质和结构，选择合适的超声波功率，对于易碎的治具，应采用较低功率。

　　Control ultrasonic power: If ultrasonic cleaning is used, excessive power may generate excessive cavitation impact force, causing damage to the fixture. The appropriate ultrasonic power should be selected based on the material and structure of the fixture. For fragile fixtures, lower power should be used.

　　清洗后的处理

　　Treatment after cleaning

　　及时干燥：清洗完成后，应尽快对治具进行干燥处理，防止水分残留导致金属治具生锈或引起其他材质治具变形。可采用热风干燥或真空干燥等方式，确保治具快速干燥。

　　Timely drying: After cleaning, the fixture should be dried as soon as possible to prevent residual moisture from causing rusting of metal fixtures or deformation of fixtures made of other materials. Hot air drying or vacuum drying can be used to ensure rapid drying of the fixture.

　　检查与保养：干燥后再次检查治具的外观和尺寸，确认是否有变形或损坏。对于清洗后出现的轻微变形，可进行适当的矫正；对于有损坏的部件，及时进行维修或更换。同时，对治具进行必要的保养，如涂抹防护油等，以延长治具的使用寿命。

　　Inspection and maintenance: After drying, check the appearance and dimensions of the fixture again to confirm if there is any deformation or damage. For slight deformations that occur after cleaning, appropriate corrections can be made; For damaged components, repair or replace them in a timely manner. At the same time, necessary maintenance should be carried out on the fixture, such as applying protective oil, to extend its service life.
